Toyota RAV4 Coil Springs

Toyota Rav4 coil springs

RAV4 Coil Springs
Are you looking to upgrade your Toyota RAV4 suspension?  Our springs are designed for 2019-2025 RAV4 models and raise the vehicle one to two inches taller, depending on the sub-model and cargo load.

We offer three versions of rear coils to best suit your vehicle’s intended purpose.
We offer RAV4 Front and Rear Coil Springs

 RAV4 LE Coil Springs
 RAV4 XLE Coil Springs
 RAV4 Adventure Coil Springs
 RAV4 Limited Coil Springs
 RAV4 TRD off-road Coil Springs
 RAV4 Hybrid Coil Springs
 Rav4 Prime Coil Springs

To find out which rear coil is best, refer to the chart below.
Contact us today to check stock and current pricing.

These heavy-duty coils will eliminate rear sag from occurring.
These Coils are stock height.
The stock coils on a Rav4 are rated at 210 pounds (95.25 kilogram) per inch, these coils rated at 370 pounds (167.83 kg)/per inch. The coils are a direct replacement for your stock coils.

2019 to 2025
TOYOTA RAV4 Adventure AWD All wheel Drive Coil Springs

2019 to 2025
TOYOTA RAV4 Hybrid AWD All wheel Drive Coil Springs

2019 to 2025
TOYOTA RAV4 Base AWD All wheel Drive

2019 to 2025
TOYOTA RAV4 TRD AWD All wheel Drive Coil Springs


RAV4 5th Generation Front Coils

                                Spring Rate    Free Height           Lift
DENDOFF HD1-F   222 LBS/IN     15" Free Height     .750"-1.00"  Lift    Support for after market front bumper and or winch, Balances load, Improved cornering & reduced sway

OE Toyota RAV4 Front Coil Springs   158 LBS/IN     15"  Free Height


RAV4 5th Generation Rear Coils

                                Spring Rate        Free Height           Lift
DENDOFF HD 1 =    305 LBS/INCH     16"                     2.00" Lift
                  Very heavy loads, towing, over landing rigs with lots of accessories and cargo

DENDOFF LS 1  =   255 LBS/INCH     17.25"                1.875" Lift
        Increased capacity for camping gear, rooftop tents, bikes etc. Smoother ride than HD springs.

DENDOFF LS 2 =   210 LBS/INCH     17.50"                1.875" Lift
                Similar feel to factory with 1.875" lift and slight capacity increase

OE Toyota RAV4 Rear Coil Springs     190 LBS/INCH     16" Free Height

We export RAV4 Coils World Wide....Ask for more details

Springs for New Toyota Highlander are coming Soon!
